3. Outside Dimensions and Part Names
14
User’s Manual
Part Names
Front
BackRight side Left side
Screen & Touch panel
Power LED
Screen adjustment switch
Power supply connector
AC adapter jack
Dip switch
Analog RGB connector
RS touch panel connector
Backlight ON/OFF connector
USB touch panel connector
Figure 3.7. Part Names
Figure 3.8. Screen Adjustment Switch
