6. Power Supply Connection
28
User’s Manual
AC Adapter Jack
The AC adapter jack is used to connect the AC adapter
[IPC-ACAP12-01] available as an option.
Do not connect any AC adapter other than the option.
+12V
GND
Figure 6.1. AC Adapter Jack
