3. Outside Dimensions and Part Names
User’s Manual
13
IPC-DT/L20S(PC)T with IPC-POA200/12-01
(power supply unit)
2.4
58
48
(0.8)
[mm]
Figure 3.5. Dimensions of IPC-DT/L20S(PC)T with
IPC-POA200/12-01
IPC-DT/H20X(PC)T with IPC-POA200/12-01
(power supply unit)
2.4
58
48
[mm]
Figure 3.6. Dimensions of IPC-DT/H20X(PC)T with
IPC-POA200/12-01
