22 Commander SK Getting Started Guide
www.controltechniques.com Issue Number: 1
Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad and
Display
Parameters
Quick Start
Commissioning
Diagnostics Options
Parameter
List
UL Listing
Information
When Pr 05 is set to PAd to implement a forward/reverse switch, see the Commander
SK Advanced User Guide.
When Pr 05 is set to E.Pot, the following parameters are made available for adjustment:
•Pr 61: Motorised pot up/down rate (s/100%)
•Pr 62: Motorised pot bipolar select (0 = unipolar, 1 = bipolar)
Figure 6-3 Pr 05 = AI.Pr Figure 6-4 Pr 05 = Pr
0V
Remote current speed
reference input (A1)
+10V reference output
+24V output
Drive Enable/Reset
(USA: Not stop)
Run Forward
(USA: Run)
Run Reverse
(USA: Jog)
Remote speed
reference input
V
_
+
+24V
0V
EUR
Analog output
(motor speed)
Digital output
(zero speed)
Reference select
Reference select
T1
T2
T3
T4
B1
B2
B3
B4
B5
B6
B7
0V
+10V reference output
+24V output
Drive Enable/Reset
(USA: Not stop)
Run Forward
(USA: Run)
Run Reverse
(USA: Jog)
V
_
+
+24V
0V
EUR
nalog output
(motor speed)
Digital output
(zero speed)
Reference select
Reference select
Not used
T1
T2
T3
T4
B1
B2
B3
B4
B5
B6
B7
T4 B7 Reference selected
00 A1
0 1 Preset 2
1 0 Preset 3
1 1 Preset 4
T4 B7 Reference selected
0 0 Preset 1
0 1 Preset 2
1 0 Preset 3
1 1 Preset 4
Figure 6-5 Pr 05 = PAd Figure 6-6 Pr 05 = E.Pot
0V
+10V reference output
+24V output
Drive Enable/Reset
Forward/Reverse
V
_
+
+24V
0V
EUR
Analog output
(motor speed)
Digital output
(zero speed)
Not used
Not used
Not used
Not used
T1
T2
T3
T4
B1
B2
B3
B4
B5
B6
B7
0V
+10V reference output
+24V output
Drive Enable/Reset
(USA: Not Stop)
Run Forward
(USA: Run)
Run Reverse
(USA: Jog)
V
_
+
+24V
0V
EUR
nalog output
(motor speed)
Digital output
(zero speed)
Down
Up
Not used
T1
T2
T3
T4
B1
B2
B3
B4
B5
B6
B7
To Next Page
