Control Techniques Commander SK2202 User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Keypad and
Display
Parameters
Quick Start
Commissioning
Diagnostics Options Parameter List
UL Listing
Information
10 Commander SK Size 2 to 6 Getting Started Guide
www.controltechniques.com Issue Number: 2
2.2 Typical short term overload limits
The maximum percentage overload limit changes depending on the induction motor only. Variations in motor rated current, motor rated power factor
and motor leakage inductance all result in changes in the maximum possible overload. The exact value for a specific motor can be calculated using
the equations detailed in Menu 4 in the Commander SK Advanced User Guide.
Table 2-1 Typical overload limits for size 2 to 5
Table 2-2 Typical overload limits for size 6
Generally the drive rated current is higher than the matching motor rated current allowing a higher level of overload than the default setting as
illustrated by the example of a typical 4 pole motor.
The time allowed in the overload region is proportionally reduced at very low output frequency on some drive ratings.
The maximum overload level which can be attained is independent of the speed.
2.3 Rating Data
Figure 2-1 Model code explanation
Table 2-3 Commander SK2, 200V drive, 3 phase, 200 to 240VAC ±10%, 48 to 65Hz units
From cold From 100% full load
Normal Duty overload with motor
rated current = drive rated current
110% for 215s 110% for 5s
Heavy Duty overload with motor
rated current = drive rated current
150% for 60s 150% for 8s
Heavy Duty overload with a typical
4 pole motor
175% for 40s 175% for 5s
From cold From 100% full load
Normal Duty overload with motor
rated current = drive rated current
110% for 165s 110% for 9s
Heavy Duty overload with motor
rated current = drive rated current
129% for 97s 129% for 15s
NOTE
SK 2 4 01
Model number within frame siz
e
Input voltage range:
2 = 200 to 240V
4 = 380 to 480V
5 = 500 to 575V
6 = 500 to 690V
Frame size
Commander SK product range
Model
number
Normal Duty Heavy Duty
Typical
full load
input
current*
Maximum
continuous
input
current*
European
input fuse
rating
IEC gG
USA Input fuse
rating
Class CC <30A
Class J >30A
Minimum
braking
resistor
value
Instantaneous
power rating
Nominal
motor
power
100% RMS
output
current
Nominal
motor
power
100% RMS
output
current
150% overload
current for 60s
kW hp A kW hp A A A A A A Ω kW
SK2201 4.0 5.0 15.5 3.0 3.0 12.6 18.9 13.4 18.1 20 20
18 8.9SK2202 5.5 7.5 22 4.0 5.0 17 25.5 18.2 22.6 25 25
SK2203 7.5 10 28 5.5 7.5 25 37.5 24.2 28.3 32 30
