Control Techniques Commander SK3402 User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Keypad and
Display
Parameters
Quick Start
Commissioning
Diagnostics Options Parameter List
UL Listing
Information
Commander SK Size 2 to 6 Getting Started Guide 19
Issue Number: 2 www.controltechniques.com
Figure 3-9 Surface mounting the size 4 drive
Figure 3-10 Surface mounting the size 5 drive
310mm (12.205in)
510mm
(20.079in)
298mm (11.732in)
258.6 0.5mm
(10.181 0.020in)
±
±
528.8
0.5mm
(20.819
0.020in
)
±
±
546.8mm
(21.528in)
18.4mm (0.724in)
25.7 0.5mm
(1.012 0.020in)
±
±
∅ 8.5mm
(0.335in)
∅ 8.5mm
(0.335in)
258.6 0.5mm
(10.181 0.020in)
±
±
25.7 0.5mm
(1.012 0.020in)
±
±
839.3
0.5mm
(33.043
0.020in)
±
±
310mm (12.205in) 298mm (11.732in)
857.3mm
(33.752in)
820mm
(32.283in)
18.4mm (0.72in)
∅ 8.5mm
(0.335in)
∅ 8.5mm
(0.335in)
