Commander SK Size 2 to 6 Getting Started Guide 57
Issue Number: 2 www.controltechniques.com
10 Parameter List
Par Description
Default
Setting 1 Setting 2
Eur USA
Level 1 parameters
01 Minimum set speed (Hz) 0.0
02 Maximum set speed (Hz) 50.0 60.0
03 Acceleration rate (s/100Hz) 5.0
04 Deceleration rate (s/100Hz) 10.0
05 Drive configuration AI.AV
06 Motor rated current (A) Drive rating
07 Motor rated speed (rpm) 1500 1800
08 Motor rated voltage (V) 230/400/575/690 230/460/575/690
09 Motor power factor (cos ϕ)0.85
10 Parameter access L1
Level 2 parameters
11 Start/Stop logic select 0 4
12 Brake controller enable diS
13
Not used
14
15 Jog reference (Hz) 1.5
16 Analogue input 1 mode (mA) 4-.20
17 Enable negative preset speeds OFF
18 Preset speed 1 (Hz) 0.0
19 Preset speed 2 (Hz) 0.0
20 Preset speed 3 (Hz) 0.0
21 Preset speed 4 (Hz) 0.0
22 Load display units Ld
23 Speed display units Fr
24 Customer defined scaling 1.000
25 User security code 0
26 Not used
27 Power up keypad reference 0
28 Parameter cloning no
29 Load defaults no
30 Ramp mode select 1
31 Stop mode select 1
32 Dynamic V to f select OFF
33 Catch a spinning motor select 0
34 Terminal B7 mode select dig
35 Digital output control (terminal B3) n=0
36 Analogue output control (terminal B1) Fr
37 Maximum switching frequency (kHz) 3
38 Autotune 0
39 Motor rated frequency (Hz) 50.0 60.0
40 Number of motor poles Auto
41 Voltage mode select Ur I
42 Low frequency voltage boost (%) 3.0
43 Serial communications baud rate 19.2
44 Serial comms address 1
45 Software version
46 Brake release current threshold (%) 50
47 Brake apply current threshold (%) 10
48 Brake release frequency (Hz) 1.0
49 Brake apply frequency (Hz) 2.0
50 Pre-brake release delay (s) 1.0
51 Post brake release delay (s) 1.0
52 Fieldbus node address 0
53 Fieldbus baud rate 0
