Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Keypad and
Display
Parameters
Quick Start
Commissioning
Diagnostics Options Parameter List
UL Listing
Information
Commander SK Size 2 to 6 Getting Started Guide 47
Issue Number: 2 www.controltechniques.com
3:3kHz
6:6kHz
12: 12kHz
See the Commander SK Technical Data Guide for drive derating data.
0: No autotune
1: Non-rotating static autotune
2: Rotating autotune
The motor must be at a standstill before a non-rotating autotune is initiated.
The motor must be at a standstill and unloaded before a rotating autotune is initiated.
Enter the motor rated frequency (taken from the motor name plate).
Defines the voltage to frequency ratio applied to the motor.
Auto: Automatically calculates the number of motor poles from the settings of Pr 07 and Pr 39
2P: Set for a 2 pole motor
4P: Set for a 4 pole motor
6P: Set for a 6 pole motor
8P: Set for an 8 pole motor
Ur S: Stator resistance is measured each time the drive is enabled and run
Ur: No measurement is taken
Fd: Fixed boost
Ur A: Stator resistance is measured the first time the drive is enabled and run
Ur I: Stator resistance measured at each power-up when the drive is enabled and run
SrE: Square law characteristic
In all Ur modes, the drive operates in open loop vector mode.
No Function Range Defaults Type
37 Maximum switching frequency 3, 6, 12 3 RW
Drive
size
Voltage
rating
3kHz 6kHz 12kHz
2All√√ √
3
SK320X √√ √
SK3401 &
SK3402
√√ √
SP3403 √√ √
SP350X √√
4All√√
5All√√
6All√√
No Function Range Defaults Type
38 Autotune 0 to 2 0 RW
When a rotating autotune is selected, the drive will
accelerate the motor up to
2
/
3
maximum speed in Pr 02.
No Function Range Defaults Type
39 Motor rated frequency 0.0 to 1500.0 Hz Eur: 50.0, USA: 60.0 RW
No Function Range Defaults Type
40 Number of motor poles Auto, 2P, 4P, 6P, 8P Auto RW
No Function Range Defaults Type
41 Voltage mode select
Ur S, Ur, Fd, Ur A, Ur l,
SrE
Ur I RW
WARNING
NOTENOTE
NOTENOTE
