Control Techniques Emerson Focus 1 User Manual

Page 18
OPERATOR FUNCTIONS
Chassis Enclosed
Speed Adjustment (Speed Pot) Standard Standard
Start/Stop Customer Supplied Standard
Forward/Reverse Optional Optional
CONTROL CIRCUIT SPECIFICATIONS
Logic Control Power 24 Vdc
Speed Potentiometer 5000 ohms
Input Signal Requirement 10 Vdc @ 0.2mA (44Kohm input resistance)
Control Circuit Isolation Optional
FOCUS 1 OPTIONS
CATALOG
NUMBER DESCRIPTION
2400-9001 M-Contactor Kit
F3DB124 Dynamic ¾ -1HP @ 240V
F3DB0524 Braking ½ HP @ 240V
F3DB112 Kits ¾ -1HP @ 120V
F3TS Toggle Switch, NEMA 4 /12
F3NSBD Signal Isolation Board
2950-9066 Remote OperatorStation ( 3 Function )
2950-9068 Remote OperatorStation ( 5 Function )
6160-9001 Ten-Turn Precision Potentiometer
Remote Percent Speed Meter Kit

Control Techniques Emerson Focus 1 Specifications

General

Brand	Control Techniques
Model	Emerson Focus 1
Category	DC Drives
Language	English
