Page 42
Start-up Guide Worksheet
At this point all INPUT POWER must be OFF !
Obtain the following information:
Focus Drive Model
2400-8000 Drive Serial Number
2400-8001 Drive Part Number _____________
a) AC Input Line Voltage 240 Vac
120 Vac
b) Motor Nameplate Information: Armature Voltage _________Vdc
Armature Current _________A
Field Voltage _________Vdc
Field Current _________A
Rated RPM _________ rpm
Regulation Mode Speed ( most common case )
Torque ( read first ! )
Focus drives come to you factory set for Speed Regulation mode which is the most
common case. Even if your application requires Torque control, we would strongly
suggest that you first run your motor Speed Control initially. After you have verified
proper operation in the Speed mode, you could then switch over to Torque mode after
reading about the Current Regulation Mode.
Improper procedures can result in personal injury or equipment damage. Only qualified electrical
maintenance technicians familiar with electronic drives and their standard safety precautions
should be permitted to install, start-up, or maintain this apparatus.
