Page 44
Armature Current Programming - (J2) Current Feedback Range
STEP 7
Set jumper J2 to the range that matches up most closely with your motors Armature Amp
rating from the table below:
FOCUS Catalog DC Output Current J2
Number (A) Jumper Position
2400-8000 5.5 Lo
or 7.5 MED
2400-8001 10 HI
When making any wiring or jumper changes, the incoming AC power must be turned of
and locked out. Hazardous voltages will be present until the AC power is turned off. The
drive contactor ( if used ) does not remove hazardous voltages when opened.
