Control Techniques FXM5 User Manual

FXM5 User Guide 19
Issue Number: 5 www.controltechniques.com
4.3.3 Procedure
Figure 4-5 Location of jumper LK3
Set the required thyristor control mode using jumper LK3.
4.4 Setting the value of I
F
max
All system control modes
4.4.1 Description
The maximum field current (I
F
max) that can be delivered by the FXM5 controller
depends on the following:
• Number of primary-winding turns through the DCCT
• Setting of jumper LK1
Refer to the following table.
Key to symbols
Half-control position
Full-control position
