FXM5 User Guide 3
Issue Number: 5 www.controltechniques.com
2Data
ThevoltagespresentintheFXM5controllerarecapableofinflictingasevere
electric shock and may be lethal. The Stop function of the Drive does not remove
dangerous voltages from the FXM5 controller or the driven machine.
AC supplies to the FXM5 controller must be disconnected at least 5 minutes
before any cover is removed or servicing work is performed.
WARNING
Electrical
Permissible AC supply voltage for the controller
power supply
220 ~ 254V ±10%
380 ~ 440V ±10%
AC supply frequency 48Hz ~ 62Hz
Permissible AC supply voltage for the thyristor
bridge
0 ~ 480V ±10%
Number of AC supply phases 1 (or across 2 phases)
Range of control of the field-winding voltage
(depending on AC supply voltage)
0V ~ 430V
Field current 20A maximum
Armature voltage 220V ~ 600VDC
Field failure relay contact ratings
250V, 3.5A DC maximum
1000VA, 200W maximum
Environmental
Ingress protection IP10 in accordance with IEC539
Operating temperature range 0°C ~ +50°C (32°F ~ 122°F)
Storage temperature range -40°C ~ +70°C (-40°F ~ 128°F)
Humidity 85% maximum, non-condensing
Derating for altitude
Maximum altitude without derating is 1000m
(3200ft). De-rate maximum field current by 1%
for each additional l00m (320ft), up to a
maximum of 4000m
Heat dissipation 75W maximum
Electromagnetic compatibility (EMC) emissions
When all the following conditions are met, the
installation can meet the requirements for
conducted emissions of EN50081-2:
The specified RFI filter (or ferrite absorber ring
and capacitor network) is used
The recommendations for the wiring
arrangements are as follows
RFI filter Steatite P2E/025/M7/-
Physical
Overall dimensions (when installed)
Width: 250mm (9.843in)
Height: 187mm (7.362in)
Depth: 112mm (4.409in)
Weight 2.5kg(6lb)
