Control Techniques Unidrive 1 Series User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Menu 0
Running
the motor
Optimisation Macros
Advanced
Parameters
Technical
Data
Diagnostics
UL Listing
Information
Unidrive User Guide 193
Issue Number: 9 www.controltechniques.com
11.1.12 Overall dimensions
H Height including surface mounting brackets
W Width
D Projection forward of panel when surface mounted
F Projection forward of panel when through-panel mounted
R Projection rear of panel when through-panel mounted
11.1.13 Weights
11.1.14 Cable sizes and fuses
11.1.15 Motor cable lengths
Dimension
Model size
12345
H
366mm
14.409in
366mm
14.409in
368mm
14.488in
765mm
30.118in
1,319mm
51.929in
W
95mm
3.740in
190mm
7.480in
375mm
14.764in
500mm
19.685in
355mm
13.976in
D
200mm
7.874in
200 mm
7.874in
260mm
10.236in
260mm
10.236in
F
120mm
4.724in
120mm
4.724in
120mm
4.724in
120mm
4.724in
340mm
13.386in
R
80mm
3.150in
80mm
3.150in
140mm
5.512in
140mm
5.512in
144mm
5.669in
Model size kg lb
1 48.8
2 817
3 22 49
4 70 154
5 Power module 102 225
5 Control module 1.2 3
Model
Typical input
current
Fuse
rating
Cable size
UNI1201 2.4 A 6A
1.5 mm
2
16 AWG
UNI1202 3.5 A 10A
2.5 mm
2
14 AWG
UNI1203 4.6 A 10A
2.5 mm
2
14 AWG
UNI1204 6.5 A 10A
2.5 mm
2
14 AWG
UNI1205 8.6 A 16A
2.5 mm
2
14 AWG
UNI2201 10.8 A 16A
2.5 mm
2
14 AWG
UNI2202 14.3 A 20A
4 mm
2
10 AWG
UNI2203 19.8 A 35A
4 mm
2
10 AWG
UNI3201 26 A 40A
6 mm
2
8 AWG
UNI3202 39 A 60A
10 mm
2
6 AWG
UNI3203 53 A 70A
16 mm
2
4 AWG
UNI3204 78 A 80A
25 mm
2
4 AWG
UNI1401 3.0 A 6A
1.5 mm
2
16 AWG
UNI1402 4.3 A 10A
2.5 mm
2
14 AWG
UNI1403 5.8 A 10A
2.5 mm
2
14 AWG
UNI1404 8.2 A 10A
2.5 mm
2
14 AWG
UNI1405 10.0 A 16A
2.5 mm
2
14 AWG
UNI2401 13.0 A 16A
2.5 mm
2
14 AWG
UNI2402 17.0 A 20A
4 mm
2
10 AWG
UNI2403 21.0 A 35A
4 mm
2
10 AWG
UNI3401 27 A 40A
6 mm
2
8 AWG
UNI3402 32 A 50A
10 mm
2
6 AWG
UNI3403 40 A 60A
10 mm
2
6 AWG
UNI3404 52 A 70A
16 mm
2
4 AWG
UNI3405 66 A 80A
25 mm
2
4 AWG
UNI4401 76 A 100A
35 mm
2
2 AWG
UNI4402 91 A 125A
35 mm
2
2 AWG
UNI4403 123 A 160A
50 mm
2
0 AWG
UNI4404 145 A 200A
70 mm
2
2/0 AWG
UNI4405 181 A 250A
95 mm
2
3/0 AWG
UNI5401 280 A 450A
120 mm
2
4/0 AWG
Nominal
AC supply
voltage
200V
Model
Maximum Permissible Motor Cable Length *
(PWM switching frequency at 3kHz **)
mft
UNI1201 65 210
UNI1202 100 330
UNI1203 130 430
UNI1204 200 660
UNI1205 300 990
UNI2201 to
UNI2203
300 990
UNI3201 to
UNI3204
200 660
