Figure 3-10 Unidrive Size 5 overall dimensions
35.5mm
(1.398in)
1248mm
(49.134in)
1319mm
(51.926in)
35.5mm
(1.398in)
315mm
(12.402in)
278mm
(10.945in)
355mm
(13.976in
)
144mm
(5.669in)
340mm
(13.386in)
484mm
(19.055in)
