Figure 10-10 Menu 5 Servo logic diagram
4.04
Current
demand
4.12
Filter time
constant
Filter
+
_
5.07
5.11
Motor rated
current
Motor number
of poles
5.02
Motor
voltage
4.02
Motor active
current
5.03
Motor power
(kW)
√ 3 x V x I
5.18
5.19
PWM
switching
frequency
High stability
space vector
modulation
Volt
Hertz
L
1
L
2
L
3
5.05
DC Bus
voltage
4.02
Motor active
current
4.13
4.14
Current loop
P gain
Current loop
I gain
Current controller
Motormap
0.XX
0.XX
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
4.20
Percentage
active
current
4.01
Motor current
magnitude
The parameters are all shown at their default settings
