11.2 Optional RFI filters
11.2.1 Ratings
N
1. 1MΩ in a star connection between phases, with the star point
connected by a 680k resistor to ground.
2. 1.5MΩ in a star connection between phases, with the star point
connected by a 680k resistor to ground.
Maximum current overload:
150% of rated current for 1 minute in a 1 hour period.
Voltage:
Phase-to-phase: 480V
Phase-to-ground: 275V
AC supply frequency:
48 to 62Hz
11.2.2 Overall dimensions
CT part
number
Schaffner part
number
Max.
continuous
current @ 40°C
(104°F)
Max.
continuous
current @ 50°C
(122°F)
Power
dissipation
at rated
current
Ground leakage current
IP rating
Discharge
resistors
Balanced supply
phase-to-phase
and
phase-to-ground
1 phase
open
circuit
4200-6104 FS5101-10-07 10 A 8.8 A 7.7 W 31 mA 143 mA IP20
See Note 1
below
4200-6105 FS5111-10-29 10 A 8.8 A 7.7 W 31 mA 143 mA IP20
4200-6108 FS5106-16-07 16 A 14.1 A 10.4 W 31 mA 143 mA IP20
4200-6109 FS5112-16-07 16 A 14.1 A 10.4 W 31 mA 143 mA IP20
4200-6113 FS5106-25-07 25 A 22.0 A 25.5 W 35.5 mA 173 mA IP20
4200-6114 FS5113-25-29 25 A 22.0 A 25.5 W 35.5 mA 173 mA IP20
4200-6116 FS5113-50-53 50 A 44.1 A 12.8 W 31 mA 143 mA IP20
See Note 2
below
4200-6117 FS5113-63-34 63 A 55.6 A 14.3 W 29 mA 126 mA IP20
4200-6106 FS5113-100-35 100 A 88.2 A 25.5 W 48.5 mA 209 mA IP20
4200-6107 FS5113-150-40 150 A 132.3 A 30.4 W 48.5 mA 209 mA IP20
4200-6111 FS5113-180-40 180 A 158.7 A 82.6 W 31 mA 143 mA IP20
4200-6112 FS5113-220-37 220 A 194.0 A 43.6 W 48.5 mA 209 mA IP20
4200-6115 FS5113-300-99 300 A 264.6 A 67.5 W 76.4 mA 407 mA IP20
See Note 1
below
NOTE
CT part Schaffner part Dimension Weight
number number H W D kg lb
4200-6104 FS5101-10-07 390 mm (15.354 in) 85 mm (3.346 in) 68 mm (2.677 in) 2.1 5
4200-6105 FS5111-10-29 240 mm (9.449 in) 45 mm (1.772 in) 95 mm (3.740 in) 1.4 3
4200-6108 FS5106-16-07 397 mm (15.630 in) 180 mm (7.087 in) 68 mm (2.677 in) 2.1 5
4200-6109 FS5112-16-07 390 mm (15.354 in) 85 mm (3.346 in) 68 mm (2.677 in) 2.7 6
4200-6113 FS5106-25-07 397 mm (15.630 in) 180 mm (7.087 in) 68 mm (2.677 in) 2.1 5
4200-6114 FS5113-25-29 255 mm (10.039 in) 73 mm (2.874 in) 95 mm (3.740 in) 2.7 6
4200-6116 FS5113-50-53 337 mm (13.268 in) 90 mm (3.543 in) 100 mm (3.937 in) 3.8 9
4200-6117 FS5113-63-34 377 mm (14.843 in) 150 mm (5.906 in) 103 mm (4.055in) 3.8 9
4200-6106 FS5113-100-35 380 mm (14.961 in) 150 mm (5.906 in) 107 mm (4.213 in) 7.8 17
4200-6107 FS5113-150-40 414 mm (16.299 in) 175 mm (6.890 in) 135 mm (5.315 in) 7.8 17
4200-6111 FS5113-180-40 502 mm (19.764 in) 170 mm (6.693 in) 157 mm (6.181 in) 15 33
4200-6112 FS5113-220-37 523 mm (20.591 in) 170 mm (6.693 in) 157 mm (6.181 in) 15 33
4200-6115 FS5113-300-99 655 mm (25.787 in) 230 mm (9.055 in) 156 mm (6.142 in) 16 35
