* Pr 11.22 and Pr 11.25 have default settings of Pr 0.12 and 9,600 (1)
respectively in Unidrive VTC when USA defaults are loaded.
Where a parameter is represented by a text value, the value in brackets
in the range column is the setting used for serial communications.
10.11 Menu 11: Menu 0 customisation / drive specific ratings
Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
11.01
Parameter 0.11 assignment Pr 0.00 to Pr 20.50 Pr 1.03 RW Uni P
11.02 Parameter 0.12 assignment Pr 0.00 to Pr 20.50 Pr 2.01 RW Uni P
11.03 Parameter 0.13 assignment Pr 0.00 to Pr 20.50 Pr 4.02 RW Uni P
11.04 Parameter 0.14 assignment Pr 0.00 to Pr 20.50 Pr 1.05 RW Uni P
11.05 Parameter 0.15 assignment Pr 0.00 to Pr 20.50 Pr 2.04 RW Uni P
11.06 Parameter 0.16 assignment Pr 0.00 to Pr 20.50 Pr 6.01 RW Uni P
11.07 Parameter 0.17 assignment Pr 0.00 to Pr 20.50 Pr 4.11 RW Uni P
11.08 Parameter 0.18 assignment Pr 0.00 to Pr 20.50 Pr 2.06 RW Uni P
11.09 Parameter 0.19 assignment Pr 0.00 to Pr 20.50 Pr 2.07 RW Uni P
11.10 Parameter 0.20 assignment Pr 0.00 to Pr 20.50 Pr 1.29 RW Uni P
11.11 Parameter 0.21 assignment Pr 0.00 to Pr 20.50 Pr 1.30 RW Uni P
11.12 Parameter 0.22 assignment Pr 0.00 to Pr 20.50 Pr 1.31 RW Uni P
11.13 Parameter 0.23 assignment Pr 0.00 to Pr 20.50 Pr 1.32 RW Uni P
11.14 Parameter 0.24 assignment Pr 0.00 to Pr 20.50 Pr 7.06 RW Uni P
11.15 Parameter 0.25 assignment Pr 0.00 to Pr 20.50 Pr 7.11 RW Uni P
11.16 Parameter 0.26 assignment Pr 0.00 to Pr 20.50 Pr 7.14 RW Uni P
11.17 Parameter 0.27 assignment Pr 0.00 to Pr 20.50 EUR> Pr 8.27, USA> Pr 6.04 RW Uni P
11.18 Parameter 0.28 assignment Pr 0.00 to Pr 20.50 EUR> Pr 4.13, USA> Pr 1.01 RW Uni P
11.19 Parameter 0.29 assignment Pr 0.00 to Pr 20.50 EUR> Pr 4.14, USA> Pr 8.23 RW Uni P
11.20 Parameter 0.30 assignment Pr 0.00 to Pr 20.50 Pr 6.13 RW Uni P
11.21 Parameter 0.30 scaling 0 to 4.000 1 RW Uni P
11.22 Initial parameter displayed {0.38}Pr 0.00 to Pr 0.50 Pr 0.10*RWUniP
11.23 Serial comms. address {0.37} 0 to 9.9 group.unit 1.1 RW Uni P
11.24 Serial comms. mode {0.32} ANSI 2 (0), ANSI 4 (1), OUtPUt (2), INPUt (3) ANSI 4 (1) RW Txt R P
11.25 Serial comms. baud rate {0.36} 4,800 (0), 9,600 (1), 19,200 (2), 2,400 (3) baud 4800 (0)* RW Txt P
11.26 Serial comms two-wire mode delay 0 to 255 ms 0 RW Uni
11.27
Serial comms. source/ destination
parameter
Pr
0.00 to Pr 20.50 0RWUniRP
11.28 Serial comms. parameter scaling 0 to 4.000 1 RW Uni
11.29 Drive software version {0.50} 1.00 to 99.99 RO Uni P
11.30 User security code {0.34}0 to 255 149RWUniSP
11.31 Drive operating mode {0.48}
OPENLP (0), CL.VECT (1), SErVO (2),
rEGEN (3)
RW Txt R P
11.32 Drive rated current (FLC) {0.33} 2.10 to 1920 A RO Uni P
11.33 Drive voltage rating 220 to 690 V RO Uni P
11.34 Drive software build number 0 to 99 RO Uni P
11.35 Number of size-5 modules connected 0 to 255 RO Uni P
11.36 Drive with slow speed fans 0 or 1
Unidrive & Unidrive VTC: 0
Unidrive LFT: 1
RO Bit P
11.37 Macro number {0.31} 0 to 9 RO Uni
11.38 Cloning module parameter set 0 to 8 0 RW Uni
11.39 Cloning module parameter set drive type
OPEN.LP (0), CL.VEct (1), SErVO (2),
rEGEN (3), FrEE (4)
4ROTxtP
11.40 Cloning module parameter checksum 0 to 16,383 RO Uni P
RO Read Only parameter
Uni Unipolar variable parameter R Reset required for new value to take effect
Bi Bipolar variable parameter S New parameter-value saved at power-down
RW Read / Write parameter
Txt Text variable parameter P Protected; forbidden as destination parameter
Bit Bit parameter FLC Full-load current (max. continuous), Pr
11.32 {0.33}
NOTE
