Control Techniques Unidrive 1403 User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Menu 0
Running
the motor
Optimisation Macros
Advanced
Parameters
Technical
Data
Diagnostics
UL Listing
Information
190 Unidrive User Guide
www.controltechniques.com Issue Number: 9
11 Technical Data
11.1 Drive
11.1.1 Power and current ratings
The input current is affected by the supply voltage and impedance.
Maximum continuous input current
The values of maximum continuous input current are given to aid the
selection of cables and fuses. These values are stated for the worst-
case condition with the unusual combination of stiff supply with bad
balance. The value stated for the maximum continuous input current
would only be seen in one of the input phases. The current in the other
two phases would be significantly lower.
• The values of maximum input current for models 1201 to 1205 are
stated for a 200Vac supply rated at ten times the kVA of the drive
and a 2% negative phase-sequence imbalance.
• The values for models 2201 to 2203 and 3201 to 3204 are stated for
a 200Vac supply having a 5kA short-circuit capability and a 2%
negative phase-sequence imbalance.
• The values for models 1401 to 1405, 2401 to 2403, 3401 to 3405
and 4401 to 4405 are stated for a 380Vac having a 16kA short-circuit
capability and a 2% negative phase-sequence imbalance.
• The values for model 5401 are stated for a 400Vac supply having an
18kA short-circuit capability and a 2% negative phase-sequence
imbalance.
Typical input current
The values of typical input current are given to aid calculations for power
flow and power loss.
• The values of typical input current for models 1201 to 1205, 2201 to
2203 and 3201 to 3204 are stated for a balanced 200Vac supply
having a 5kA short-circuit capability.
• The values for models 1401 to 1405, 2401 to 2403 and 3401 to 3405
are stated for a balanced 400Vac supply having a 5kA short-circuit
capability.
• The values for models 4401 to 4405 are stated for a balanced
400Vac supply having a 10kA short-circuit capability.
• The values for model 5401 are stated for a balanced 400V supply
having an 18kA short-circuit capability.
* Multiples of 300A output current with 120% overload or multiples of
240A with 150% overload
Table 11-1 Unidrive and Unidrive VTC drive current ratings
Nominal rating
Maximum permissible continuous output
current at 40
°C (104°F) ambient (A)
Maximum permissible continuous output
current at 50°C (122°F) ambient (A)
Typi cal
input
current
(A)
Maximum
continuous
input
current (A)
Model kW hp 3kHz 4.5kHz 6kHz 9kHz 12kHz 3kHz 4.5kHz 6kHz 9kHz 12kHz
UNI1201 0.37 0.5 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.4 4.0
UNI1202 0.55 0.75 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 3.5 6.0
UNI1203 0.75 1.0 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.3 4.6 8.0
UNI1204 1.1 1.5 5.6 5.6 5.6 5.6 4.5 5.6 5.6 5.1 4.0 3.3 6.5 10.0
UNI1205 2.2 3.0 9.5 9.5 8.5 7.0 5.5 6.9 5.9 5.1 4.0 3.3 8.6 12.5
UNI2201 3.0 4.0 12.0 12.0 12.0 12.0 11.7 12.0 12.0 12.0 11.6 9.7 10.8 13.9
UNI2202 4.0 5.0 16.0 16.0 16.0 14.2 11.7 16.0 16.0 14.7 11.6 9.7 14.3 16.9
UNI2203 5.5 10.0 25.0 21.7 18.2 14.2 11.7 20.0 17.3 14.7 11.6 9.7 19.8 27.0
UNI3201 7.5 15 34.0 34.0 34.0 28.0 23.0 34.0 34.0 28.0 21.0 17.9 26 28
UNI3202 11.0 20 46.0 46.0 40.0 32.0 26.6 44.0 36.0 31.0 24.0 20.6 39 43
UNI3203 15.0 25 60.0 47.0 40.0 32.0 26.7 44.0 36.0 31.0 24.0 20.9 53 56
UNI3204 22.0 30 74.0 56.0 46.0 35.0 28.0 50.0 41.0 34.0 26.0 23.0 78 84
UNI1401 0.75 1.0 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 3.0 4.5
UNI1402 1.1 1.5 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 2.8 4.3 5.5
UNI1403 1.5 2.0 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.3 5.8 6.8
UNI1404 2.2 3.0 5.6 5.6 5.6 5.6 4.5 5.6 5.6 5.1 4.0 3.3 8.2 8.6
UNI1405 4.0 5.0 9.5 9.5 8.5 7.0 5.5 6.9 5.9 5.1 4.0 3.3 10.0 12.0
UNI2401 5.5 7.5 12.0 12.0 12.0 12.0 11.7 12.0 12.0 12.0 11.6 9.7 13.0 16.0
UNI2402 7.5 10 16.0 16.0 16.0 14.2 11.7 16.0 16.0 14.7 11.6 9.7 17.0 20.0
UNI2403 11.0 15 25.0 21.7 18.2 14.2 11.7 20.0 17.3 14.7 11.6 9.7 21.0 25.0
UNI3401 15.0 25 34.0 34.0 34.0 28.0 23.0 34.0 34.0 28.0 21.0 17.9 27 34
UNI3402 18.5 30 40.0 40.0 37.0 28.0 23.0 40.0 34.0 28.0 21.0 17.9 32 39
UNI3403 22.0 30 46.0 46.0 40.0 32.0 26.6 44.0 36.0 31.0 24.0 20.6 40 53
UNI3404 30.0 40 60.0 47.0 40.0 32.0 26.7 44.0 36.0 31.0 24.0 20.9 52 66
UNI3405 37.0 50 70.0 56.0 46.0 35.0 28.0 50.0 41.0 34.0 26.0 23.0 66 82
UNI4401 45 75 96 96 88 70
95 85 75 60 76 98
UNI4402 55 100 124 104 88 70
105 85 75 60 91 114
UNI4403 75 125 156 124 105 80 135 105 85 65 123 152
UNI4404 90 150 180 175 145 110
180 150 125 95 145 205
UNI4405 110 150 202 175 145 110
190 150 125 95 181 224
UNI5401 160 200 300* 240 280 321
UNI5402 320 400 600*
480 560 642
UNI5403 480 600 900*
720 840 963
UNI5404 640 800 1,200* 960 1,120 1284
UNI5405 800 1000 1,500*
1,200 1,400 1605
UNI5406 960 1200 1,800*
1,440 1,680 1926
UNI5407 1120 1400 2,100* 1,680 1,960 2247
UNI5408 1280 1600 2,400*
1,920 2,240 2568
