Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
9.01
Prog.-logic function 1 output indicator 0 or 1 RO Bit P
9.02 Prog.-logic function 2 output indicator 0 or 1 RO Bit P
9.03 Motorized pot. output indicator ±100.0 % RO Bi S P
9.04
Prog.-logic function 1 input 1 source
parameter
Pr
0.00 to Pr 20.50 Pr 0.00 RW Uni P
9.05 Prog.-logic function 1 input 1 invert 0 or 1 0 RW Bit
9.06
Prog.-logic function 1 input 2 source
parameter
Pr
0.00 to Pr 20.50 Pr 0.00 RW Uni P
9.07 Prog.-logic function 1 input 2 invert 0 or 1 0 RW Bit
9.08 Prog.-logic function 1 output invert 0 or 1 0 RW Bit
9.09 Prog.-logic function 1 delay 0 to 25.0 s 0 RW Uni
9.10
Prog.-logic function 1 destination
parameter
Pr
0.00 to Pr 20.50 Pr 0.00 RW Uni R P
9.14
Prog.-logic function 2 input 1 source
parameter
Pr
0.00 to Pr 20.50 0RWUniP
9.15 Prog.-logic function 2 input 1 invert 0 or 1 0 RW Bit
9.16 Prog.-logic function 2 input 2 source Pr 0.00 to Pr 20.50 Pr 0.00 RW Uni P
9.17 Prog.-logic function 2 input 2 invert 0 or 1 0 RW Bit
9.18 Prog.-logic function 2 output invert 0 or 1 0 RW Bit
9.19 Prog.-logic function 2 delay 0 to 25.0 s 0 RW Uni
9.20
Prog.-logic function 2 destination
parameter
Pr
0.00 to Pr 20.50 Pr 0.00 RW Uni R P
9.21 Motorised pot. zero-start select 0 or 1 0 RW Bit
9.22 Motorised pot. bipolar select 0 or 1 0 RW Bit
9.23 Motorised pot. rate 0 to 250 s 20 RW Uni
9.24 Motorised pot. output scale factor 0 to 4.000 1 RW Uni
9.25 Motorised pot. destination Pr 0.00 to Pr 20.50 Pr 0.00 RW Uni R P
9.26 Motorised pot. up 0 or 1 RO Bit
9.27 Motorised pot. down 0 or 1 RO Bit
9.28 Motorised pot. reset 0 or 1 RO Bit
9.29 Binary-sum logic ones (MSB) 0 or 1 RO Bit
9.30 Binary-sum logic twos 0 or 1 RO Bit
9.31 Binary-sum logic fours 0 or 1 RO Bit
9.32 Binary-sum logic output value 0 to 7 RO Uni P
9.33 Binary-sum logic destination parameter Pr 0.00 to Pr 20.50 Pr 0.00 RW Uni R P
RO Read Only parameter
Uni Unipolar variable parameter R Reset required for new value to take effect
Bi Bipolar variable parameter S New parameter-value saved at power-down
RW Read / Write parameter
Txt Text variable parameter P Protected; forbidden as destination parameter
Bit Bit parameter FLC Full-load current (max. continuous), Pr
11.32 {0.33}
