Converteam LV7000 - Ethernet, Introduction; Ethernet

2 Ethernet Board Technical Data
2-2 Ethernet Option Board / 700.002 735 AE01
2.3 Ethernet, introduction
The Ethernet consist of different layers shown in the picture below. Due to the modular structure of Ethernet it
is easy to add new protocols such as fieldbus or user interfaces to the Converteam Ethernet option board in
the future.
Figure 2-2: Ethernet layer structure
2.4 Ethernet
Common use-cases of Ethernet – devices are ‘human to machine’ and ‘machine to machine’. Basic features
of these two use-cases are presented in the pictures below.
1. Human to machine (Graphical User interface, relatively slow communication)
Figure 2-3: HMI communication
1
Physical
2 Data
Link
3
Network
4
Transport
5
Session
6
Presentatio
7
Applicatio
Ethernet Physical
Layer
Ethernet Data Link
Layer
IP
TCP
UDP
Protocol
Layer
(HTTP, DHCP , Modbus/TCP, Ethernet /
IP, etc)
1
Physical
2 Data
Link
3
Network
4
Transport
5
Session
6
Presentatio
7
Applicatio
Ethernet Physical
Layer
Ethernet Data Link
Layer
IP
TCP
UDP
Protocol
Layer
(HTTP, DHCP , Modbus/TCP, Ethernet /
IP, etc)
Ethernet Physical
Layer
Ethernet Data Link
Layer
IP
TCP
UDP
Protocol
Layer
(HTTP, DHCP , Modbus/TCP, Ethernet /
IP, etc)
