6 Error Codes and Errors
Ethernet Option Board /
700.002 735 AE01
6-1
6 Error Codes and Errors
6.1 Frequency Converter Error Codes
To make sure that the board functions are correctly in all circumstances and that no errors occur, the board
set the fieldbus error 53 if it doesn't have a functional connection to the Ethernet network or if the connection
is faulty.
In addition, the board assumes that there is always at least one functional connection after the first
Modbus/TCP connection. If this is not true, the board will set the fieldbus error 53 in the frequency converter.
Confirm the error by pressing the 'reset' button.
Card slot error 54 may be due to a faulty board, a temporary malfunction of the board or a disturbance in the
environment.
6.2 Modbus TCP
This section discusses Modbus/TCP error codes used by the OPT-CI board and possible causes of the errors.
Code Modbus exception Possible cause
0x01 Illegal function The appliance does not support the function
0x02 Illegal data address Attempt to read the query over the memory
range
0x04 Slave device failure The appliance or connections are faulty
0x06 Slave device busy Simultaneous query from two different masters
to the same memory range
Table 6-1: Error Codes
