3 Installation
Ethernet Option Board / 700.002 735 AE01 3-1
3 Installation
3.1 Installing the Ethernet Option Board in a Converteam LV7000 Unit
Note: MAKE SURE THAT THE FREQUENCY CONVERTER IS SWITCHED OFF BEFORE AN
OPTION OR FIELDBUS BOARD IS CHANGED OR ADDED!
A
Converteam LV7000 frequency converter.
B
Remove the cable cover.
C
Open the cover of the control unit.
