Service manual OEB/OES/OGB/OGS
AS/11-2011 / Item: 7006209 6_03e_Software update via SD Card Black Box_b
Page 3 / 3
6.3.2 Sequence of the update procedure
The entire software update procedure may last 3-6 minutes, depending on the scope of the
update.
a)
If necessary, store your own recipes in the IDM.
b)
Store IDM information in cache memory (only necessary in software version 4.03 or
older)
:
1) Switch Convotherm on using the On / Off button.
2) If necessary, answer the question after the DE flushing with “no”.
3) Switch to the Service level (3-button manoeuvre).
4) Via the Service programme c12 or c13, select the
“Dummy Version”
(c12 on 300, c13 on 999)
5) Switch to c14 and exit the Service level.
6) Press the On / Off button for 5 seconds to restart the electronics.
7) Switch Convotherm on using the On / Off button.
8) If necessary, answer the question after the DE flushing with “no”.
9) Switch to the Service level.
10) Via the Service programme c12 or c13, select the “Dummy Version”
(c12 on 300, c13 on 999).
11) Switch to c14 and exit the Service level.
12) Press the On / Off button for 5 seconds to restart the electronics.
c)
Disconnect appliance from the mains.
d)
Remove Operating Mode (BM) panel (pull forwards and place on the top of the
appliance), but do not disconnect the cable from the BM. The BM panel must
have a direct conducting metal contact with the Convotherm during the
programming procedure.
e)
Remove X12 connection plug from the Control Module (SM).
f)
Plug SD card in SD card box, taking care to position the SD card correctly.
g)
Connect the SD card box with the Control Module (slot X18 at the top of the
SM), if necessary, remove an existing Communications Module (KM) or cable.
h)
Fasten black earth cable from the black box to the Convotherm housing, using
a crocodile clip.
i)
Reconnect appliance to the mains.
j)
Programming starts automatically and can last 3 to 6 minutes. If programming
and initialisation are successful, the time and date are displayed on the BM and
the green LED is lit permanently on the SD card box.
Should after about 7 minutes the date not be displayed and the red LED is
flashing as well as the green one being permanently lit, without removing the SC
card, disconnect the appliance from the mains and reconnect it; wait until the date
is in the display and the green LED on the SD card box is permanently lit.
k)
Disconnect appliance from the mains.
l)
Disconnect SD card box from the Convotherm and, if necessary, reconnect the
previously disconnected KM or cable to SM X18.
m)
Reconnect X12 to the SM.
n)
Check that the other plugs are firmly inserted (SM and, if necessary, also the
gas module GM)
o)
Re-insert the BM panel.
p)
Reconnect appliance to the mains.
q)
Switch appliance on.
r)
If necessary, reset desired language.
s)
If necessary, reload the recipes stored under point a) from the IDM.
