Pin No. Denition Pin No. Denition Pin No. Denition
1 VBUS 8 D1- 15 SSTX2-
2 SSRX1- 9 D1+ 16 GND
3 SSRX1+ 10 NC 17 SSRX2+
4 GND 11 D2+ 18 SSRX2-
5 SSTX1- 12 D2- 19 VBUS
6 SSTX1+ 13 GND 20 No Pin
7 GND 14 SSTX2+
12) F_U32 (USB 3.2 Gen 1 Header)
The header conorms to USB 3.2 Gen 1 and USB 2.0 specication and can provide two USB ports. For
purchasing the optional 3.5" ront panel that provides two USB 3.2 Gen 1 ports, please contact the local
dealer.
11) SPEAKER (Speaker Header)
Connects to the speaker on the chassis ront panel. The system reports system startup status by issuing
a beep code. One single short beep will be heard i no problem is detected at system startup.
Pin No. Denition
1 VCC
2 NC
3 NC
4 SPK-
1
10
20 1
11
Prior to installing the USB bracket, be sure to turn o your computer and unplug the power cord
rom the power outlet to prevent damage to the USB bracket.
13) F_USB1 (USB 2.0/1.1 Header)
The header conorms to USB 2.0/1.1 specication. Each USB header can provide two USB ports via an
optional USB bracket. For purchasing the optional USB bracket, please contact the local dealer.
Pin No. Denition Pin No. Denition
1 Power (5V) 6 USB DY+
2 Power (5V) 7 GND
3 USB DX- 8 GND
4 USB DY- 9 No Pin
5 USB DX+ 10 NC
9
1
10
2
