Cooper WaveLinx Wired - Page 4

12 Circuit Cabinet
Weight
Packed: 160 lbs (72 Kg)
Unpacked: 132 lbs (60 Kg)
24 Circuit Cabinet
Weight
Packed (24): 220 lbs (100 Kg)
Unpacked (24): 200 lbs (90 Kg)
4.13 in.
(105 mm)
4.13 in.
(105 mm)
56.7 in.
(1440 mm)
56.7 in.
(1440 mm)
4.13 in.
(105 mm)
4.13 in.
(105 mm)
9.78 in.
(248.5 mm)
9.78 in.
(248.5 mm)
4.45 in.
(113 mm)
4.45 in. (113 mm)
7.6 in.
(193 mm)
7.6 in.
(193 mm)
20.3 in.
(517 mm)
27.8 in.
(707 mm)
Ø 0.89 in.
(22.5 mm)
Ø 0.89 in.
(22.5 mm)
0.98 in.
(25 mm)
0.98 in.
(25 mm)
4.53 in.
(115 mm)
4.53 in.
(115 mm)
1.1 in.
(28 mm)
1.1 in.
(28 mm)
1.1 in.
(28 mm)
1.1 in.
(28 mm)
1.1 in.
(28 mm)
1.1 in.
(28 mm)
13.76 in.
(349.5 mm)
13.76 in.
(349.5 mm)
Knockouts for Supply
and Load Wiring Only
Knockouts for Supply
and Load Wiring Only
Knockouts for Low
Voltage Control
Wiring Only
Knockouts for Low
Voltage Control
Wiring Only
Ø 2.42 in.
Ø 2.42 in.
61.5 mm
61.5 mm
Universal Source Controller - Feed ThruWaveLinx Wired
9850-000234-02 page 4
May 2024
