Specications
The numerous models within the Universal Source Controller
range share the following key specifications. Information
specific to each cabinet model are provided elsewhere
throughout this guide.
• All channels provide switched (non-dim) and dimmed high
voltage load control as standard
• Leading-edge triac dimmer engines capable of
withstanding repetitive inrush currents of 50 times
operating current without impacting lifetime
• All dimming and switching circuitry for every channel
located on individual boards for quick and easy swap-out,
if necessary
• Voltage and frequency compensation to maintain light
level during supply fluctuations
• Power monitoring for each circuit and the total panel
• Bypass jumpering fitted as standard to protect circuits
and allow work lighting during installation
• Selectable low voltage load control available per channel
for dimmable ballast control
• Low maintenance and quiet operation thanks to fanless,
convection cooled operation
• Support for multiple control protocols: iCAN for links
to multiple control sources; DMX512A for links with
entertainment systems; RS-485 for integration with
building management schemes and ethernet for
connection to a variety of systems
• Dual volt-free switch inputs, with programmable
responses, for integration with emergency control
devices, building management systems, etc
• Compact wall mounted design with easy access to all
internal items and lockable front panel door for added
security
• Intuitive control panel provides straightforward
programming and configuration of the system. The
control panel allows a base level installation to be
configured without the use of separate PC programming
• Overcurrent protection provided externally in field
installation (Per Canadian electrical code)
Safety
Please Read This First
The Universal Source Controllers are designed, built and
tested to strict safety regulations. By following the steps
listed below and elsewhere within this guide, you can ensure
safe installation and operation of these controller units.
• The Universal Source Controllers must be installed only by
a qualified electrician
• The installation must comply with the appropriate
electrical codes and regulations in force in your area
• The Universal Source Controllers are designed for indoor
installation and use only. The units can, however, be used
to control appropriately certified exterior lighting fixtures
• Ensure that all wiring used conforms fully to local
specifications and is sufficiently rated for the installation
• All new wiring must be fully verified before applying power
• The high voltage supply should be fed to the Universal
Source Controller via an external isolation breaker with
sufficient capacity for the planned installation
• All Universal Source Controllers exceed the weight limit
for one person lifting - always use at least two people
when lifting and mounting the units
• Do not mix load types within a single channel (e.g. 120V
tungsten and low voltage ballast control)
• Ensure that the supply is fully isolated at an external
breaker before removing the chassis covers. Test that
power has been removed before starting to handle
conductors
• Ensure that high voltage and low voltage wiring remains
separate
• Each dimmer channel should be protected by its own
dedicated external circuit breaker.
Important Points For Consideration
• The Universal Source Controllers must be mounted flush
with the wall, do not recess the controller chassis
• Upper and lower raceways must not be located within 8
inches (200 mm) of the upper and lower panels of the
Universal Source Controller. Use suitable conduits and
couplers to link the raceways to the controller chassis
• Allow adequate space for future maintenance of the unit.
Do not install in a location that will later be difficult to
access
• The Universal Source Controllers are designed to be
mounted vertically
• During operation, the Universal Source Controllers
will produce audible noise caused by electrical noise
suppression circuitry and also the circuit relays within
the unit. The noise is a low level buzz that varies with
the level of dimming and also clicks when relays are
energised. Take these matters into consideration when
deciding on a suitable mounting position.
• The hinged cover must be unscrewed and removed from
the front cover when the Universal Source Controller
operates at full load in a high ambient environment
