Description of the rotary switch LEDs
The table below shows the value of the selected parameter and the corresponding voltage value. Each LED corresponds
to a different parameter. The default parameter values are saved to permanent memory.
LED W1
Not used
LED W2
Warning level
The operator can set the warning threshold.
See the table below for the voltage value corresponding to the selected setting.
LED W3
Alarm level
The operator can set the alarm threshold.
See the table below for the voltage value corresponding to the selected setting.
LED W4
Modbus address
The operator can set the Modbus address.
To set the values with greater precision, use the Modbus serial connection or the app.
See the table below for the voltage value corresponding to the selected setting.
LED W5
Alarm delay
The operator can select the delay time for activation of the LED and the alarm relay after the alarm threshold has been
exceeded.
See the table below for the voltage value corresponding to the selected setting.
LED W6
Type of Analog output voltage.
The operator can select the type of Analog output.
See the table below for the voltage value corresponding to the selected setting.
LED W7
Alarm/warning reset function mode
This parameter is used to select the warning and alarm reset modes.
0 = manual reset (latch) / 1 = automatic reset
LED W8
Modbus configuration
The operator can choose the desired Modbus configuration from the options available.
See the table below for the voltage value corresponding to the selected setting.
Possible configurations - Alarm/warning reset function mode (W7)
W=0
A=0
Manual reset
Warning
Manual reset
Alarm
W=1
A=0
Automatic reset
Warning
Manual reset
Alarm
W=0
A=1
Manual reset
Warning
Automatic reset
Alarm
W=1
A=1
Automatic reset
Warning
Automatic reset
Alarm
