Copeland C Series User Manual

28
Input register 102 bits
Bit Description Long description Fault Service Port Error Code
0 No reply from SM Yes 1 V
1 No reply from sensor Yes 2 V
2 Preheating From sensor, 1 during preheating
3 Reserved Internal use only
4 Over range Over range from sensor 5 V
5 Under range Under range from sensor Yes 3 V
6 Reserved For internal use only
7 Reserved For internal use only
8 Reserved For internal use only
9 Reserved For internal use only
10 ServiceDue SM reporting service due
11 SensorExpired SM reporting sensor expired
12 N/A
13 Reserved For internal use only
14 Reserved For internal use only
15 N/A
Function 05 Write Single Coil & Function 01 Read Coils
Address Register Name Short description
Medium
description
Long description
Max
Value
Min
Value
Unit of
Measure
Modbus
Bit pos.
Modbus
Length
Default
Value
401 ServiceDue Service needed Maintenance
indicator (Including
calibration)
1 = maintenance
required
1 0 0 1 0
402 Acknowledge Acknowledge Manually
acknowledge
warning or alarm
Write 1 to
acknowledge
1 0 0 1 0
403 RelayFailSafe Relay FailSafe Relay in failsafe
mode
1 = Relay in failsafe
mode
1 0 0 1 0
404 RelayWF Relay WF Warning relay used
as fault
1 = Warning relay
used as fault
1 0 0 1 0
405 Acknowledge
Warning
Acknowledge
warning
Manual/
automatic warning
acknowledgement
setting
1 = automatic reset;
0 = manual reset
1 0 0 1 0
406 Acknowledge
Alarm
AcknowledgeAlarm Manual/
automatic alarm
acknowledgement
setting
1 = automatic reset;
0 = manual reset
1 0 0 1 1
407 ZeroCalibrati on Zero calibration Start zero calibration
command
1 = start calibration 1 0 0 1 1
408 SpanCalibration SpanCalibration Start span
calibration
command
1 = start span
calibration
1 0 0 1 0
409 FactoryReset Reset Reset the detector
to the factory
settings
1 = restore factory
settings
1 0 0 1 0
