Use and maintenance manual – 10/2016 Rev. 3 Page 4
ALWAYS UNPLUG THE POWER SUPPLY CABLE FROM THE SOCKET BEFORE MOVING THE MACHINE.
The environmental working conditions must comply with the following requirements:
- Temperature from 0° C to + 45° C
- Relative humidity from 20% to 95%
5. UNPACKING
After removing packing, check integrity of machine making sure there are no visibly damaged parts.
In case of doubt DO NOT USE THE MACHINE and consult qualified personnel (dealer or manufacturer). The packaging materials
(plastic bags, nails, screws pieces of wood, etc.) must not be left within reach of children as they are potential sources of danger.
Packaging materials should be stored in the appropriate collection points if non-biodegradable pollutants.
CHECK THE PRESENCE OF THE BOX CONTAINING THE ACCESSORIES TO AVOID THROWING IT WITH
PACKING.
6. INSTALLATION AND COMMISSIONING
After unpacking the various parts of the wheel balancer, ensure they are intact and check for any anomalies, then assemble the parts
by following the instructions provided below.
6.1 Installing the display head
010 Unscrew nr. 4 M6 screws.
020 Fit the sheet metal rear support by running the
cables as shown in Figure F6.2 and screw no. 4 M6
screws (Figure F6.3).
030 Prepare the sheet metal front support by running
the cables as shown in F6.4.
040 Fit the sheet metal front support.
