Cormach MOTO MEC - Machine Dimensions; Working Range

Use and maintenance manual – 10/2016 Rev. 3 Page 10
10.1 Machine dimensions
Depth
mm. 420
Width
mm. 640
Height
mm. 1250
10.2 Working range
Rim size manually set
mm.
inches
Rim – machine distance
2 ÷ 460
Rim width
50 ÷ 500
2.0 ÷ 20.0
Rim diameter
25 ÷ 890
1.0 ÷ 35.0
Wheel features
Maximum wheel diameter
1120 mm.
Maximum wheel width
590 mm.
Max. wheel weight
70 kg.
Machine weight (without accessories)
80 Kg.
Noise level
< 70 dB(A)
Table T10.1: Functions for machine model
Functions
MEC 1
NOTES
Data wheel manual acquisition
•
Balancing accuracy
± 0.5 g.
FMB Parking brake pedal
•
Distance gauge with extension
•
MFC Motorbike wheels calibration with zero-settings of the unbalance in the
flange
•
Static/Dynamic balancing
•
Grams/ounces selection
•
Inches/mm selection
•
Wheel programs for MOTO/QUAD ALU1, DYNAMIC and STATIC
•
STATIC program
•
DYNAMIC program
•
HIDDEN WEIGHTS program
•
STAND BY function
•
Service programs
•
