4
620919541
DRAIN LINE
1-IN. I.D. PLASTIC TUBING
(6 FT) WITH INSULATION
SOLVENT BOND
HOSE CLAMP
BARB ADAPTER
1 BARB X 3/4 MPT
COUPLING
3/4 SOCKET X 3/4 FPT
DRIP TRAY DRAIN
FITTING
FIGURE 2. DRIP TRAY DRAIN ASSEMBLY
