Cornelius DF-250 - Figure 3. Mounting Template

5
620919541
12
OPENING
30
23
21–1/4
29
9–3/16 11–5/8
18–5/8
1–5/16
1–13/16
26–7/16
7/16
30–11/16
21–1/4
23–1/16
RECOMMENDED COUNTER OPENING SIZE
9.00 X 12.00 FOR UTILITIES AND
BEVERAGE TUBING. OPENING CAN BE LOCATED
ANYWHERE WITHIN THE SHADED AREA.
REMOVABLE DRIP TRAY
TO FRONT OF DRIP TRAY
ON COUNTERTOP
TO FRONT TOP OF
DRIP TRAY
Z STYLE
9
3–1/2
FIGURE 3. MOUNTING TEMPLATE
