Cornelius DF-250 - Figure 5. Flow Diagram (Pneumatic Ice Gate)

7
620919541
ICE GATE CYLINDER REVERSE
SINGLE ACTING-SPRING EXTENDED
PNEUMATIC GATE SOLENOID VALVE
3-WAY NORMALLY CLOSED
FILTER–REGULATOR
(FACTORY-SET OUTLET
PRESSURE TO 32-36 PSIG)
MANUAL OVERIDE SOLENOID VALVE
3-WAY NORMALLY CLOSED
CO2 SUPPLY
50 PSIG MAX.
FIGURE 5. FLOW DIAGRAM (PNEUMATIC ICE GATE)
