8.2.1 Flushing-in of sanitization agent into syrup side (e.g. P3 Ansep CIP from Ecolab)
The product lines filled with syrup must first be flushed with water. For this an external water distributor can
be used to connect and flush several syrup lines simultaneously. The post-mix valves should be operated on the
syrup side only for flushing.
Attention !
Gas driven syrup pumps must not see any positive pressures on the incoming side of the pump, as
this may damage the pumps.
Connect the water distributor to the CO
2
supply in order to drive the water out of the syrup lines. This avoids
that the sanitizing agent is being diluted in the tubing. Afterwards close the CO
2
gas and depressurize the
complete system again.
Fill your cleaning tank with the cleaning / sanitizing agent according to the mixing ratios given by the
manufacturer of the agent. (e.g. when using P3 from ECOLAB -> 50ml for 1 litre water = 5% solution) In
order to achieve a proper mixing in the cleaning tank, it is recommended to first fill in the agent and then top-
of with clean water.
Connect the syrup lines to the cleaning tank and dispense cleaning / sanitization agent from every single
dispense valve. Make sure that agent leaves from all installed taps.
8.2.2 Flushing-in of sanitization agent into water side (e.g. P3 Ansep CIP from Ecolab)
Close the water- + the CO
2
supply to the unit and depressurize the system with the taps
Disconnect the water supply to the unit and cut the power supply to the carbonator pump in order to avoid dry
running of the pump (e.g. by pulling the plug of the pump).
Connect the water line feeding the dispenser to CO
2
gas pressure and drain all water from the tubing of the
system. This ensures that the sanitizing agent that is afterwards flushed into the dispenser is not being diluted
e.g. in the carbonator bowl. Afterwards close the gas supply again and depressurize the system.
Connect the cleaning tank to the water inlet of the dispenser and pressurize the tank with approx. 3 bars
pressure (Attention ! Remove any water filters before doing this !)
Pull the safety relieve valve on the carbonator bowl and carefully let some sanitizing agent leave the valve.
This ensures, that the carbonator bowl is flooded completely with sanitizing agent all the way to the top.
Attention ! : Avoid that excessive amounts (= >50ml) of agent is being introduced into the water
bath, as this will carry the risk of corrosion of metal parts in the water bath. In case larger amounts
were spilled, the water in the water bath needs to be replaced.
Flood the complete dispense system with the cleaning / sanitizing agent by operating the post-mix valves.
Ensure, that on all
valves clearly visible agent is being drawn.
Effect- / working time for the cleaning / sanitizing agent is min. 20 minutes !!
In the meantime remove the dispense nozzles from the valves and sanitize them manually by putting them for
20 minutes into sanitizing agent. In case it is seen that the nozzles are heavily dirty, clean the nozzles
mechanically by using a clean brush and sanitization agent.
8.2.3 Flushing-out of sanitization agent out of syrup side (e.g. P3 Ansep CIP from Ecolab)
Disconnect the cleaning tank and bring out any remaining sanitizing agent from the syrup lines by using CO
2
gas. Afterwards close the CO
2
supply and depressurize the system via the dispense valves.
Connect the water distributor and sufficiently flush clean water through the syrup lines (for this please open
only the syrup side of the dispense valves). In case a hygiene water filter is being used with the dispenser, it is
recommended to use for this flushing the water coming from the hygiene filter.
