PHYSICAL DIMENSIONS
Figure 2. Physical Dimensions
TOOLS REQUIRED
Table 2
Screw driver, phillips #2 & #1 Oetiker crimping tool
Tube cutter
Needle nose plier 8”/200 mm Snap ring plier 8”/200 mm
3/32” Allen key
Adjustable Wrench 30 mm Safety Gloves
Safety Goggles & Shoes
C-Box
UI Display
485.0 mm
288.0 mm
92.0 mm
116.0
mm
198.0 mm
43.0 mm
