FMFV - Installation Manual
Publication Number: 919000012INS - 5 - © 2018-19, Cornelius Inc.
FMFV- SYSTEM OVERVIEW
FMFV: Description
The Frozen Multi flavour Valve (FMFV) is a pneumatically actuated valve that has the capability to dispense single
or dual-flavoured frozen drinks. The valve’s operation is achieved by using compressed air at a pressure of 45 psig.
The FMFV kit comes with 3 sub systems:
1.C-Box
2.Valve assembly
3.UI Display
FMFV: Features
The FMFV Kit provides the following features:
• Digital Interface: User-Friendly touch screen control
• Variety: 8 flavours on each barrel deliver up to 36 different flavour combination from one barrel
• Technology: Electro-pneumatic dispense valves removes the need to touch the valve
• Pulsed dispensing: Electronically controlled flavour valve actuation to maintain ratio during dual flavour
dispensing
• Mixology: Ability to combine and personalize flavour
FMFV: Specifications
Table 1
Model Specifications
Flavour Ratio 30:1
Flavour flow rate 6ml/sec (0.203 oz/Sec)
Drink Flow rate
200 - 250 ml/sec (6.76 - 8.45
oz/Sec)
Operational Relative Humidity range 30-80% RH
Operational Temperature Range 23.8°-40.5°C (75°F-105°F)
Electrical Requirements 230V 50/60 Hz
User Interface (Touch Screen) 122.4 X 91.44 mm (7 in.)
Shipping Weight 12.27 Kg (27 lb)
Operating Pressure 276-310 k Pa (40-50 psig)
Agency Listing NSF, CE
IP Rating IP CLASS 20
