COMPONENT SERVICE
The following are procedure for replacing the major components of the Kit.
DIFFUSER REPLACEMENT
1. Defrost the System (Ref Viper product manual)
2. Dispense all the Base Syrup in the Respective Viper barrel
3. Remove front panel turn OFF 3 way valve
4. Disconnect power to the Unit.
5. Loosen the grub screw and remove the pneumatic Cylinder
6. Remove the Diffuser fin from bottom of diffuser body by unscrewing
7. Replace the Diffuser body
SIDE SEAL
1. Turn barrel “OFF” from menu
2. Remove the Side cap and Injector Module
3. Remove existing seals and assemble new seals
CYLINDER SPRINGS
1. Defrost the System (Ref Viper product manual)
2. Dispense all the base Syrup in the respective viper barrel
3. Loosen the grub screw and remove the Pneumatic Cylinder
4. Open the Pneumatic cylinder by Removing the Top Cover
5. Remove existing lengthier spring and Insert New springs
PISTON O-RING
1. Defrost the System (Ref Viper product manual)
2. Dispense all the base Syrup in the respective viper barrel
3. Loosen the grub screw and remove the Pneumatic Cylinder
4. Remove existing seal and assemble new seal
MAC VALVE
1. Disconnect power to the Unit.
2. Shut off the compressed air/Co2 at source
3. Remove the pneumatic Hose and Injector module out of the Valve
4. Take out the C-Box and place it on flat surface
5. Remove the side panel, Disconnect the inlet and out let pneumatic connections of the mac valve
6. Disconnect the electrical harness
7. Remove existing Mac Valve and assemble new mac valve
