Header Locations
SYSFAN1
USB2 PARALLEL
SPEAK
TX-RXCOM
SYSFAN2
JP14
FPANEL
SM_BUS
TPM
KBMS
CPUFAN
PWR_LED
COM6
USB1
NIC2_LED
NIC1_LED
FP_AUDIO
SPDIF
GPIO
COM5
COM3
COM4
USB3
