Chapter 1 Technical Specifications
The Q77AX is a long-life industrial motherboard with multi-core processor technology and PCI
Express 2.0 and 3.0 support (depending on the processor). Powered by the Intel® Q77 Express
chipset (Panther Point), the Q77AX motherboard was designed specifically for embedded
applications such as Medical, Security, Imaging, Industrial Automation, and Manufacturing that
require a smaller, compact footprint.
Embedded Processor (1155 LGA package)
Intel XEON E3-1225 3.10GHz, 4 cores/ 4 threads, 6M cache, 95W
Intel® Core™ i7-3770 3.40GHz, 4 core/ 8 threads, 8M cache, 77W
Intel® Core™ i7-2600 3.40GHz, 4 core/ 8 threads, 8M cache, 95W
Intel® Core™ i5-3550S 3.00GHz, 4 core/ 4 threads, 6M cache, 65W
Intel® Core™ i5-2400 3.10GHz, 4 core/ 4 threads, 6M cache, 95W
Intel® Core™ i3-3220 3.30GHz, 2 core/ 4 threads, 3M cache, 55W
Intel® Core™ i3-2120 3.30GHz, 2 core/ 4 threads, 3M cache, 65W
Intel® Pentium™ G2120 3.10GHz, 2 core/ 2 threads, 3M cache, 55W
Intel® Pentium™ G850 2.90GHz, 2 core/ 2 threads, 3M cache, 65W
Intel® Celeron™ G540 2.50GHz, 2 core/ 2 threads, 2M cache, 65W
Non-Embedded Processors
For additional supported processors, please contact your Sales Representative.
Chipset
BD82Q77 PCH
Four DDR3 1666,1333 or 1066MHz DIMM sockets
Up to 32GB of non-ECC memory
Intel® Integrated Graphics.
One VGA port resolution of 2048x1536@75Hz
(QXGA)
One DVI-D port
One Displayport
Four SATA 3Gb/s ports with Intel® Rapid Storage
Technology RAID support (0, 1,5 and 10)
Two SATA 6Gb/s ports with Intel® Rapid Storage
Technology RAID support (0, 1)
Intel® AMT 8.0 support
Multi-monitor support
