Corvalent Q77AX - NB PCIe and Memory Configuration

61
► NB PCIe Configuration
PEG0
PEG0 – Gen X
Auto, Gen1, Gen2 or Gen3
PEG0 ASPM
Disabled, Auto, ASPM L0s, ASPM L1 or ASPM L0sL1
Enable PEG
Disabled, Enabled or Auto
De-emphasis Control
-6dB or -3.5dB
► Memory Configuration
Memory Information
Memory Frequency
1333MHz
Total Memory
4096 MB (DDR3)
DIMM#1 20486 MB (DDR3)
DIMM#2 Not Present
DIMM#3 2048 MB (DDR3)
DIMM#4 Not Present
CAS Latency (tCL) 9
CAS to RAS (tRCDmin) 9
Row Precharge (tRPmin) 9
Active to Precharge (tRASmin) 24
XMP Profile 1 Not Supported
XMP Profile 2 Not Supported
DIMM profile
Default, Custom, Profile 1 or Profile 2
Memory Frequency Limiter
Auto, 1067, 1333 or 1600
NMode Support
Auto, 1N or 2N
Memory Remap
Enabled or Disabled
