8
Peripheral Chips
Fintek F71869AD SIO chip)
Two full handshake COM ports
PS/2 keyboard and mouse header
Hardware voltage monitor /CPU temp. monitor
Watchdog timer
PWM fan control outputs / tachometer inputs
CPU thermal diode monitoring
Fintek F81216AD Four full handshake COM ports
System Memory
Four DIMM sockets, supporting up to 32GB of unbuffered non-ECC DDR3 memory. X16 memories not
supported
BIOS
AMIBIOS BIOS 64Mb SPI
Embedded I/0
Serial Ports (6)
6 full handshake RS232 serial ports
COM3 configurable to RS-232C/RS-422/RS485
RI pin configurable on COM1, COM3 and COM4
USB Interfaces (12)
4 USB2.0 ports on back I/O (black)
2 USB3.0 ports on back I/O (blue)
2 USB2.0 ports on 2x5 10-pin headers
2 USB3.0 ports on 2x10 20-pin header
Keyboard/Mouse Header
Combined PS/2 Keyboard and mouse on 6 pin
header
Video Support
DB-15 VGA connector on back-I/O
(Maximum resolution 2048x1536 @75Hz)
DVI-D connector on back I/O
Displayport
Line-in, Line-out, MIC stacked connector and front
panel audio header
Audio ALC886
6 channel HD Audio codec
SPDIF
