Below is an example of the RAID Configuration Screen
[MAIN MENU]
1. Create RAID Volume 2. Reset Disks to Non-RAID
3. Delete RAID Volume 4. Recovery Volume Options
5. Exit
[DISK/VOLUME INFORMATION]
RAID Volumes:
ID Name Level Strip Size Status Bootable
0 Volume0 RAID1(Mirror) N/A 1.8TB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 WDC WD2002FYPS-0 WD-WCAVY0341261 1.8TB Member Disk(0)
1 WDC WD2002FYPS-0 WD-WCAVY6653212 1.8TB Member Disk(0)
Loading the Intel Matrix Storage Technology RAID Driver
1.
Begin Windows Setup by booting from the Windows Installation CD.
2.
At the beginning of Windows Setup, press <F6> to install third-party SCSI or RAID driver. When
prompted, insert the diskette with the Intel Matrix Storage Technology RAID Driver. These drivers are
available on you Driver CD and need to be copied to a floppy disk. (Note: a USB floppy drive may be
used if the system does not have a floppy drive).
3.
Install the Intel SATA RAID driver.
4.
Finish the Windows Installation and install all necessary drivers.
Note: Windows 7 does not require the use of an F6 driver.
