49
►PCI Express Link Settings
Relaxed Ordering
Enable or Disable
Extended Tag
Enable or Disable
No Snoop
Enable or Disable
Maximum Payload
Auto or select
Maximum Read Request
Auto or select
PCI Express Link Register Settings
ASPM Support
Disable, Auto or Force LOs
Warning: Enabling ASPM may
cause some PCI-E devices to fail
Extended Synch
Enable or Disable
Link Training Retry
Disabled, 2, 3 or 5
Link Training Timeout (uS)
100
Unpopulated Links
Keep Link ON or Disable Link
