Adjustingthepumpoperatingmode

1  Minimumproportionalpressurecurve,PP1
2Middleproportionalpressurecurve,PP2

3Maximumproportionalpressurecurve,PP3

4Minimumconstantpressurecurve,CP1

5Middleconstantpressurecurve,CP2

6Maximumconstantpressurecurve,CP3

7Minimumconstantcurve,I

8
Middleconstantcurve,II

9Maximumconstantcurve,III
Proportional
pressure adjustment
ranges
Differential pressure
adjustment ranges
Constant pressure
adjustment ranges
