36
3. Control parameters and display channels
3.1 Overview of channels
Legend:
x
Corresponding channel is available.
x*
Corresponding channel is available when the corre-
sponding option is enabled
Only if the option heat quantity measurement is ac-
tivated (OHQM), will the corresponding channel be
available.
MEDT
Only if an antifreeze (MEDT) other than waterorTyfo-
cor
®
LS/G-LS(MEDT0or3) is used, will the channel
antifreeze concentration (MED%) be displayed.
Only if the option heat quantity measurement is de-
activated (OHQM), will the corresponding channel be
available.
Pleasenote:
Only if temperature sensors are connected, will S3 and
S4 be displayed.
channel description page
COL x Temperature collector 37
TST x Temperature store 37
S3 x Temperature sensor 3 37
TRF
Temperature return sensor 37
S4
Temperature sensor 4 37
n % x Pump speed relay 1 37
h P x Operating hours relay 1 38
kWh
Heat quantity kWh 38
MWh
Heat quantity MWh 38
time x time 37
DT O x
Switch-on temperature
difference
39
DT F x
Switch-off temperature
difference
39
DT S x Set temperature difference 39
RIS x Rise 39
S MX x Maximum temperature store 39
EM x Emergency temperature collector 40
channel description page
OCX x Option collector cooling collector 40
CMX x* Maximum temperature collector 40
OCN x Option minimum limitation collector 40
CMN x* Minimun temperature collector 40
OCF x Option antifreeze collector 41
CFR x* Antifreeze temperature collector 41
OREC x Option recooling 41
O TC x Option tube collector 41
OHQM
x
Option heat quentity measurement 38
FMAX
Maximum flowrate 38
MEDT
Antifreeze type 38
MED% MEDT Antifreeze concentration 38
nMN x Minimum pump speed relay 1 39
HND x Manual operation relay 1 42
LANG x Language 42
BS4 X.XX Version number
