34
TYPICAL FLEXIBLE CONNECTION
1. Turn manual shut-off valve to the closed position.
2. Unplug range or disconnect power.
3. If necessary, locate and remove the regulator cover on the back of the
range.
IMPORTANT: Do not remove the gas pressure regulator.
1/2" Adapter
1/2" Adapter 1/2" or 1/4"
Gas pipe
Flexible connector
(6 ft. max.)
Gas shut-off valve
Pressure
regulator
Gas flow into range
Regulator
cover
