35
Function
Command and description
BIT9
0:No UTP Protection
1: UTP Protection
BIT10
0:No OLPH Protection
1: OLPH Protection
BIT11
0:No OLPL Protection
1: OLPL Protection
 Status definition refer to Table 36. Status definition
Query the SP series DC input
voltage of the battery
Format: VBAT?
Query the SP series output
power
Format: PINV?
Reset default
Format:*RST
Select the Setup Menus with the
help of Function Codes
Format : FUNC <Function Code>
Function code
Setting Menu
0
OVP setting
1
OVP Recovery
2
UVP Setting
3
UVP Recovery
5
RS-232 Baud-rate
6
Retry Time
Query the functions No
Format: FUNC?
Query the setting value of the
function
Format: SETT?
Set or adjust the value of the
function
Format: SETT <value>
Table 34. RS-232 interface command
SP-700 ~ SP-2000 Status Definition
Description
Definition
OLPL Protection
OLPL: Over Load Protection Low (101~115%)
Sof Fail Protection
Sof Fail: Soft Start Fail
Poff Protection
Poff: Power off
UVP Protection
UVP: Under Voltage Protection
OVP Protection
OVP: Over Voltage Protection
OLPM Protection
OLPM: Over Load Protection Middle (116~200%)
OLPH Protection
OLPH: Over Load Protection High (>200%)
OTP Protection
OTP: Over Temperature Protection
UTP Protection
UTP: Under Temperature Protection
OOCP Protection
OOCP: Output Over Current Protection
Table 35. SP-700 ~ SP-2000 Status Definition
