36
EN
SP-3000 ~ SP-4000 Status Definition
Description
Definition
ID
ID: ID Connection Error
Sof Fail Protection
Sof Fail: Soft Start Fail
PLL
PLL: Phase lock loop
Poff Protection
Poff: Power off
OOCP Protection
OOCP: Output Over Current Protection (Over Load >
200%)
OVP Protection
OVP: Over Voltage Protection
UVP Protection
UVP: Under Voltage Protection
OTP Protection
OTP: Over Temperature Protection
UTP Protection
UTP: Under Temperature Protection
OLPH Protection
OLPH: Over Load Protection High (116~200%)
OLPL Protection
OLPL: Over Load Protection Low (101~115%)
Table 36. SP-3000 ~ SP-4000 Status Definition
The following data shows the function code detail setting value.
Note:
Below setting value will go back to default value by switching on / off
the inverter.
5-3-2-1. FUNC 0 : OVP setting
SETT <value>
Default
Model
15.0 ~ 16.5
16.5V <16.5>
SP series-112 / 212
30.0 ~ 33.0
33.0V <33.0>
SP series-124 / 224
60.0 ~ 66.0
66.0V <66.0>
SP series-148 / 248
Table 37. OVP setting
5-3-2-2. FUNC 1 : OVP Recovery
SETT <value>
Default
Model
13.5 ~ 14.5
14.5V <14.5>
SP series-112 / 212
27.0 ~ 29.0
29.0V <29.0>
SP series-124 / 224
54.0 ~ 58.0
58.0V <58.0>
SP series-148 / 248
Table 38. OVP recovery
5-3-2-3. FUNC 2 : UVP setting
SETT <value>
Default
Model
10.5 ~ 11.5
10.5V <10.5>
SP series-112 / 212
21.0 ~ 23.0
21.0V <21.0>
SP series-124 / 224
42.0 ~ 46.0
42.0V <42.0>
SP series-148 / 248
Table 39. UVP setting
