COTLIN L Series - Remove Panel; Evaporator Clean

File No: 1.9.01.00018 Version No:A
Note: Subsequent update versions of this manual will not be noticed.thank you.
service@cotlin.top
12 / 24
14.1 Remove Front Panel and Top Panel of Ice Maker

Remove front panel of ice maker, there is a screw on the top cover plate of the ice maker and on the lef
t
and right of the front panel, please use a Phillips screwdriver to remove the screw;
 First, move the front panel gently to your own direction until you see that the connecting line stops
moving, pull the connecting line to completely remove the front panel;

Demolish the top cover plate of ice machine Hold the top cover against the front panel, gently lift
up, and then gently push back, that is, the top cover should be lowered；
14.2 Evaporator Cleaning
 Scrub the surface of the evaporator with a brush or sponge;
